This Pro-D Anemometer measures Wind Speed and wind direction when connected to a wind speed data logger like the new WindLogger, WindTracker or our GSM systems.
Pro-D Anemometer comes with wind speed sensor, wind vane and fixings for a 2" pipe (you need to provide wind mast only), 13 meters cable and accessories for installation.
Sensor Type: Wind Speed - Wind Cups and magnetic switch Wind Direction - Wind Vane and potentiometer
Attached Cable Length: 13m (40ft)
Cable Type: 4-conductor, 26 AWG
Material: Wind Vane and Control Head: UV-Resistant ABS
Wind Cups: Polycarbonate
Anemometer Arm: Black-anodized aluminum
Dimensions: 381mm L x 38mm W x 457mm H
Wind Direction Output:
Constructed of rugged Lexan cups molded in one piece for repeatable performance. Includes calibration certificate.
A four-pole magnet induces a sine wave voltage into a coil producing an output signal with frequency proportional to wind speed. The #40C is constructed of rugged Lexan cups molded in one piece for repeatable performance. A rubber terminal boot is included.
This anemometer is often used for wind resource assessment for wind turbines, they are 1% accuracy and have a resolution better than 0.1m/s to match the IEC-61400-12 standards for wind measurement and wind turbine performance analysis.
The #40C anemometers are manufactured with exceptional quality control meeting new standards- all units are tested mechanically and electronically before shipping.
This anemometer is compatible with our GSM wind monitoring system only
