This Pro-D Anemometer measures Wind Speed and wind direction when connected to a wind speed data logger like the new WindLogger, WindTracker or our GSM systems.
Pro-D Anemometer comes with wind speed sensor, wind vane and fixings for a 2" pipe (you need to provide wind mast only), 13 meters cable and accessories for installation.
Sensor Type: Wind Speed - Wind Cups and magnetic switch Wind Direction - Wind Vane and potentiometer
Attached Cable Length: 13m (40ft)
Cable Type: 4-conductor, 26 AWG
Material: Wind Vane and Control Head: UV-Resistant ABS
Wind Cups: Polycarbonate
Anemometer Arm: Black-anodized aluminum
Dimensions: 381mm L x 38mm W x 457mm H
Wind Direction Output:
Constructed of rugged Lexan cups molded in one piece for repeatable performance. Includes calibration certificate.
A four-pole magnet induces a sine wave voltage into a coil producing an output signal with frequency proportional to wind speed. The #40C is constructed of rugged Lexan cups molded in one piece for repeatable performance. A rubber terminal boot is included.
This anemometer is often used for wind resource assessment for wind turbines, they are 1% accuracy and have a resolution better than 0.1m/s to match the IEC-61400-12 standards for wind measurement and wind turbine performance analysis.
The #40C anemometers are manufactured with exceptional quality control meeting new standards- all units are tested mechanically and electronically before shipping.
This anemometer is compatible with our GSM wind monitoring system only
This vane is directly connected to a precision conductive plastic potentiometer located in the main body. An analog voltage output directly proportional to the wind direction is produced when a constant DC excitation voltage is applied to the potentiometer. A rubber terminal boot is included.
Sensor type continuous rotation potentiometric wind direction vane
Sensor range 360° mechanical, continuous rotation
Accuracy potentiometer linearity within 1%
Dead band 8° Maximum, 4° Typical
This sensor is compatible with GSM wind site assessment devices
Download more information
This anemometer has been designed for the acquisition of the horizontal component of the wind speed in the field of meteorology and wind energy measuring technology. The anemometer meets all requirements of IEC 61400-12-1 for an Instrument of the accuracy class 0.5
Special characteristics are minimal over-speeding, low starting value and according to Accuwind (testreport1), probably one the best sensors in the market when it comes to measuring wind speed.
This product has a lead time of 1-2 weeks, it also requires specific connectors. Please contact us for any questions.View full product details
